# Sorting on the GPU
Dealing with sorted data make most algorithms easier to work with, so it makes sense that we would want to be able to sort our GPU data on the GPU. We have to rethink how we approach sorting as the way we do it as traditional sorting algorithms aren't designed with parallel computing power in mind. Fortunately there are some algorithms out there that do work well with the GPU!
# Odd-Even Sort (aka. Brick Sort)
This sort works by iterating over pairs of items, comparing them, and swapping them if one is greater than the other. Consider the following array:
[3, 7, 1, 5, 0, 4, 2, 6]
First we do the odd pass. This means that we consider pairs of items from index 1 (not 0) up. So for the above data, the pairs would be the following.
[[7, 1], [5, 0], [4, 2]]
We skip the first and last term as those are don't have another number next to them that isn't already paired up. We then swap the higher number with the lower number meaning our data looks as follows:
[3, 1, 7, 0, 5, 2, 4]
Next is the even pass. This the same as the odd pass, but we start at index 0 instead of 1. This gives us the following pairs.
[[3, 1], [7, 0], [2, 4]]
Which when swap yields the following:
[1, 3, 0, 7, 2, 4]
This process repeats until the array is sorted. Here's the data at each iteration after this:
[1, 0, 3, 2, 7, 4] // odd
[0, 1, 2, 3, 4, 7] // even
# When do we stop sorting?
Most sorting algorithms don't manually check that the array is sorted
after each iteration. Fortunately research shows (opens new window)
that the max number of iterations to complete this algorithm is the
same as the number of items, ie N. This means that given an array of
size N = 8
[7, 6, 5, 4, 3, 2, 1, 0]
It will take 8 passes to sort this data.
[7, 5, 6, 3, 4, 1, 2, 0] // odd
[5, 7, 3, 6, 1, 4, 0, 2] // even
[5, 3, 7, 1, 6, 0, 4, 2] // odd
[3, 5, 1, 7, 0, 6, 2, 4] // even
[3, 1, 5, 0, 7, 2, 6, 4] // odd
[1, 3, 0, 5, 2, 7, 4, 6] // even
[1, 0, 3, 2, 5, 4, 7, 6] // odd
[0, 1, 2, 3, 4, 5, 6, 7] // even
This will always work, regardless of the data we are sorting. It's a little inefficient when your data is almost sorted, so you'll want to keep that in mind.
# Porting odd-even sort to WGSL
The odd-even sort is special as each pass is trivial to parallelize. Each pair of items is considered independantly of all the other items. That means that we can dedicate a single thread to every pair we want to compare. Let's jump into the shader!
@group(0)
@binding(0)
var<storage, read_write> data: array<u32>;
@compute
@workgroup_size(64, 1, 1)
fn odd_even_sort(
@builtin(global_invocation_id)
gid: vec3<u32>,
) {
// ...
}
This works much the same as with the introduction code. We setup our bindgroup
with one array<u32> that is read_write as this sort works without needing
an additional array to output into. We also only need the global_invocation_id
builtin to properly index our data. No we'll start looking at the code inside
of odd_even_sort.
let num_items = arrayLength(&data);
let pair_index = gid.x;
First we get the index of the pair the current thread is working on.
// odd
var a = pair_index * 2u + 1;
var b = a + 1u;
if a < num_items && b < num_items && data[a] > data[b] {
let temp = data[a];
data[a] = data[b];
data[b] = temp;
}
For this part of the code, first we get the indices of the items we want to compare. If the indices are in bounds and the values are out of order, swap the values. We can do the even pass as well so that we can halve the number of times we call this shader.
// even
a = pair_index * 2u;
b = a + 1u;
if a < num_items && b < num_items && data[a] > data[b] {
let temp = data[a];
data[a] = data[b];
data[b] = temp;
}
It seems like we're done with the shader code, but there's technically an error in our code. It's nothing with the logic of our code, it has to do with the nature of parallel coding in general: race conditions.
# Race conditions and barriers
A race condition occurs when two or more threads try to opperate on the same location in memory. If we did one step for each call to the shader, we would be fine, but since we do two passes, we need to make sure that the threads aren't tripping over each other. We do this using barriers.
A barrier causes the current thread to wait for other threads to finish before continuing. There are two types of barrier.
A workgroupBarrier will cause all the threads in the workgroup to wait
until all other threads in the work group have reached the barrier. It
will also sync up all atomic variables and data stored in workgroup address
space as well.
In WGSL and "address space" determines how a certain chunk of can be access.
Data in the workgroup address space is only accessible by threads within
the same workgroup. Many of the address spaces are implicit such as the
function address space. The uniform and storage address spaces are
significant as they correspond to uniform buffers and storage buffers
respectively.
A storageBarrier will cause the GPU to sync all changes to storage buffers.
Since our data is in a storage buffer, this is the barrier we need to
ensure that things stay in sync. Add the following line between the odd and
even passes.
storageBarrier();
With that the odd_even_sort function looks like this:
@compute
@workgroup_size(64, 1, 1)
fn odd_even_sort(
@builtin(global_invocation_id)
gid: vec3<u32>,
) {
let num_items = arrayLength(&data);
let pair_index = gid.x;
// odd
var a = pair_index * 2u + 1;
var b = a + 1u;
if a < num_items && b < num_items && data[a] > data[b] {
let temp = data[a];
data[a] = data[b];
data[b] = temp;
}
storageBarrier();
// even
a = pair_index * 2u;
b = a + 1u;
if a < num_items && b < num_items && data[a] > data[b] {
let temp = data[a];
data[a] = data[b];
data[b] = temp;
}
}
# Calling the shader
Most of the code is the same as the introduction code, with the exception of only creating one storage buffer and the following code to call the shader:
let num_items_per_workgroup = 128; // 64 threads, 2 items per thread
let num_dispatches = (input_data.len() / num_items_per_workgroup) as u32
+ (input_data.len() % num_items_per_workgroup > 0) as u32;
// We do 2 passes in the shader so we only need to do half the passes
let num_passes = input_data.len() / 2 + input_data.len() % 2;
{
let mut pass = encoder.begin_compute_pass(&Default::default());
pass.set_pipeline(&pipeline);
pass.set_bind_group(0, &bind_group, &[]);
for _ in 0..num_passes {
pass.dispatch_workgroups(num_dispatches, 1, 1);
}
}
With this, your data should be sorted. You can now use it for whatever purpose you need such as sorting transparent objects by their z coordinate, or sorting objects by what cell the belong to in a grid for collision detect and resolution. We'll be using sorting to implement some different algorithms in other parts of this guide.
# Conclusion
Sorting is one of the pillars of software development and now that we can sort our GPU data without sending it on a round trip to the GPU. We'll be using this a lot in the rest of this guide.
